Drum Screen

Drum Screen

Processing capacity: 12–150 t/h
Feeding size: 50–150 mm
Screen layer: 1–2
Screen size: 1–40 mm
Power: 0.5–5.5 kw
Material handling: slag, coal gangue, sand, gravel aggregate, etc


Drum screen is suitable for classifying powdery materials with outstanding screening effect. The screen mesh is 60-200; power is 0.75-3 kw and output is 500-1500 kg/h.



1. The angle of inclination of installation is small and the machine is not very easy to be blocked.

2. Drum screen covers a small size

3. Low noise and little powder dust pollution

4. Stable operation

5. High screening efficiency

6. Big output

7. Convenient installation


Technical data

Model Yield(m³/h) Power
Sieve hole(2mm) Sieve hole(30mm)
YTS1230 12 100 5.5
YTS1240 14 120 5.5
YTS1250 15 140 5.5
YTS1530 18 150 5.5
YTS1540 18 150 7.5
YTS1550 20 180 11
YTS1560 22 200 11
YTS2040 25 250 15
YTS2050 30 300 15
YTS2060 35 350 18.5
