Electrostatic Precipitator

Electrostatic Precipitator

Processing air quantity: 37000–378000 m3/h
Working temperature: 400 ℃
Bearable pressure: 6000 Pa
Designed efficiency: ≥99.9
Material handling: dust, etc

Overview

Electrostatic precipitator is composed of control box, boosting transformer and rectifier. The voltage outputted by the power supply also has great influence on the efficiency of the dust efficiency, for this reason, the running voltage of the electrostatic precipitator should be maintained in the range of 40-75KV and even over 100KV.

Advantages

Compared with other dust collecting equipment, electrostatic precipitator has low energy consumption and high efficiency and it can be used in the sites with high temperature and pressure of smoke. Practice shows that the higher the amount of the smoke to be processed is, the lower the investment and operational cost of the electrostatic precipitator will be.

Its purification work is mainly completed through two systems: discharge electrode and receiving electrode. When high pressure direct current is inputted between the two electrodes, anion and cation will be produced in the space of the electrodes and will function on the surface of the waste particles that go through the static electric field. The waste particles will move to the opposite electrode under the field stress and deposit on the electrode, thus achieving the aim of dust collection. There is rapping apparatus on both sides of the system, and when the rapping hammer periodically hits the two sides, the powder dust that stick onto it will be shaken off and fall to the ash bucket and will be discharged from the machine.

Technical data

Model Effective Section Processing Air Quantity(m3/h) Max. Working Temperature(℃) Bearable Pressure(Pa) Air Speed in the Electric Field(m/s) Designed Efficiency Dust Content in Feeding Mouth(g/Nm³) Dust Content in Discharging Mouth(g/Nm³) Resistance Loss(Pa)
15-III 15 37000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
20-III 20 51000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
30-III 30 756000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
40-III 40 100000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
50-III 50 126000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
60-III 60 152000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
70-III 4 177000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
80-III 08 210000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
90-III 09 230000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
100-III 100 252000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
110-III 110 280000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
120-III 120 300000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
140-III 140 353000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
150-III 150 378000 400 6000 0.7-0.9 ≥99.9 <500 <50mg <200
